关于 ios:cornerRadius with border: Glitch around border

cornerRadius with border: Glitch around border

我的应用程序主要是基于圆形和边框的。

我使用 UIView 的 layer 属性来给出圆角半径和边框。

但我面临一个问题，角落不清晰。

我得到以下结果：

UI按钮

screenshot

UIImageView

screenshot

您可以观察到白色或灰色边框周围的细边框线。

这是我的代码：

1
2
3
4
5

button.layer.borderWidth = 2.0;
button.layer.borderColor = [[UIColor whiteColor] CGColor];
button.layer.cornerRadius = 4;

button.clipsToBounds = YES;

我已经想办法解决这个问题，但没有成功。

我试过button.layer.masksToBounds = YES，但没有效果。

我错过了什么吗？或者与 CALayer 相比，还有其他方法可以给我更好的结果吗？

相关讨论

当borderWith也是一个整数时会出现故障吗？
为了测试我尝试了borderWidth 1.5、2.0、2.5和3.0，但我得到了同样的故障。

我尝试了很多解决方案，最后使用 UIBezierPath.

我创建了 UIView 的类别并添加了制作圆形矩形和边框的方法。

这是该类别的方法：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37

– (void)giveBorderWithCornerRadious:(CGFloat)radius borderColor:(UIColor *)borderColor andBorderWidth:(CGFloat)borderWidth
{
CGRect rect = self.bounds;

//Make round
// Create the path for to make circle
UIBezierPath *maskPath = [UIBezierPath bezierPathWithRoundedRect:rect
byRoundingCorners:UIRectCornerAllCorners
cornerRadii:CGSizeMake(radius, radius)];

// Create the shape layer and set its path
CAShapeLayer *maskLayer = [CAShapeLayer layer];

maskLayer.frame = rect;
maskLayer.path = maskPath.CGPath;

// Set the newly created shape layer as the mask for the view’s layer
self.layer.mask = maskLayer;

//Give Border
//Create path for border
UIBezierPath *borderPath = [UIBezierPath bezierPathWithRoundedRect:rect
byRoundingCorners:UIRectCornerAllCorners
cornerRadii:CGSizeMake(radius, radius)];

// Create the shape layer and set its path
CAShapeLayer *borderLayer = [CAShapeLayer layer];

borderLayer.frame = rect;
borderLayer.path = borderPath.CGPath;
borderLayer.strokeColor = [UIColor whiteColor].CGColor;
borderLayer.fillColor = [UIColor clearColor].CGColor;
borderLayer.lineWidth = borderWidth;

//Add this layer to give border.
[[self layer] addSublayer:borderLayer];
}

我从这篇精彩的文章中了解到使用 UIBezierPath 的想法：Thinking like a B??zier path

我从这两个链接中获得了大部分代码：

UIView 类别仅用于舍入您想要的角，而不是像 CALayercornerRadius 一样。
如何在 UIBezierPath 上获得边框

注意：这是类别方法，因此它自己表示调用该方法的视图。像 UIButton、UIImageView 等。

相关讨论

这是非常好的解决方案。当用 layer.cornerRadius 圆角时，我遇到了黑色轮廓细的奇怪问题，我使用您发布的代码片段修复了它。谢谢！
您忘记使用borderColor 参数；)
@KamilNomtek.com borderLayer.strokeColor = [UIColor whiteColor].CGColor;用于边框颜色。

这是@CRDave 的 Swift 5 版本作为 UIView 的扩展：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

protocol CornerRadius {
func makeBorderWithCornerRadius(radius: CGFloat, borderColor: UIColor, borderWidth: CGFloat)
}

extension UIView: CornerRadius {

func makeBorderWithCornerRadius(radius: CGFloat, borderColor: UIColor, borderWidth: CGFloat) {
let rect = self.bounds

let maskPath = UIBezierPath(roundedRect: rect,
byRoundingCorners: .allCorners,
cornerRadii: CGSize(width: radius, height: radius))

// Create the shape layer and set its path
let maskLayer = CAShapeLayer()
maskLayer.frame = rect
maskLayer.path = maskPath.cgPath

// Set the newly created shape layer as the mask for the view’s layer
self.layer.mask = maskLayer

// Create path for border
let borderPath = UIBezierPath(roundedRect: rect,
byRoundingCorners: .allCorners,
cornerRadii: CGSize(width: radius, height: radius))

// Create the shape layer and set its path
let borderLayer = CAShapeLayer()

borderLayer.frame = rect
borderLayer.path = borderPath.cgPath
borderLayer.strokeColor = borderColor.cgColor
borderLayer.fillColor = UIColor.clear.cgColor
borderLayer.lineWidth = borderWidth * UIScreen.main.scale

//Add this layer to give border.
self.layer.addSublayer(borderLayer)
}

}

这是 Kamil Nomtek.com 更新到 Swift 3 的答案，并进行了一些改进(主要是语义/命名和使用类协议)。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35

protocol RoundedBorderProtocol: class {
func makeBorder(with radius: CGFloat, borderWidth: CGFloat, borderColor: UIColor)
}

extension UIView: RoundedBorderProtocol {
func makeBorder(with radius: CGFloat, borderWidth: CGFloat, borderColor: UIColor) {
let maskPath = UIBezierPath(roundedRect: bounds, byRoundingCorners: .allCorners, cornerRadii: CGSize(width: radius, height: radius))

// Create the shape layer and set its path
let maskLayer = CAShapeLayer()
maskLayer.frame = bounds
maskLayer.path = maskPath.cgPath

// Set the newly created shape layer as the mask for the view’s layer
layer.mask = maskLayer

//Create path for border
let borderPath = UIBezierPath(roundedRect: bounds, byRoundingCorners: .allCorners, cornerRadii: CGSize(width: radius, height: radius))

// Create the shape layer and set its path
let borderLayer = CAShapeLayer()

borderLayer.frame = bounds
borderLayer.path = borderPath.cgPath
borderLayer.strokeColor = borderColor.cgColor
borderLayer.fillColor = UIColor.clear.cgColor

//The border is in the center of the path, so only the inside is visible.
//Since only half of the line is visible, we need to multiply our width by 2.
borderLayer.lineWidth = borderWidth *?2

//Add this layer to display the border
layer.addSublayer(borderLayer)
}
}

CRDave 的答案很有效，但有一个缺陷：当多次调用时，如大小更改，它会不断添加层。相反，应该更新以前的图层。
有关更新的 ObjC 版本，请参见下文。为了迅速，请相应地适应。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56

// UIView+Border.h
#import <UIKit/UIKit.h>

@interface UIView (Border)
– (void)setBorderWithCornerRadius:(CGFloat)radius
color:(UIColor *)borderColor
width:(CGFloat)borderWidth;
@end

// UIView+Border.m
#import”UIView+Border.h”

@implementation UIView (Border)
– (void)setBorderWithCornerRadius:(CGFloat)radius
color:(UIColor *)borderColor
width:(CGFloat)borderWidth {
CGRect rect = self.bounds;

//Make round
// Create the path for to make circle
UIBezierPath *maskPath = [UIBezierPath bezierPathWithRoundedRect:rect
byRoundingCorners:UIRectCornerAllCorners
cornerRadii:CGSizeMake(radius, radius)];

// Create the shape layer and set its path
CAShapeLayer *maskLayer = [CAShapeLayer layer];

maskLayer.frame = rect;
maskLayer.path = maskPath.CGPath;

// Set the newly created shape layer as the mask for the view’s layer
self.layer.mask = maskLayer;

//Give Border
//Create path for border
UIBezierPath *borderPath = [UIBezierPath bezierPathWithRoundedRect:rect
byRoundingCorners:UIRectCornerAllCorners
cornerRadii:CGSizeMake(radius, radius)];

// Create the shape layer and set its path
NSString *layerName = @“ig_border_layer”;
CAShapeLayer *borderLayer = (CAShapeLayer *)[[[self.layer sublayers] filteredArrayUsingPredicate:[NSPredicate predicateWithFormat:@“name == %@”, layerName]] firstObject];
if (!borderLayer) {
borderLayer = [CAShapeLayer layer];
[borderLayer setName:layerName];
//Add this layer to give border.
[[self layer] addSublayer:borderLayer];
}

borderLayer.frame = rect;
borderLayer.path = borderPath.CGPath;
borderLayer.strokeColor = [UIColor whiteColor].CGColor;
borderLayer.fillColor = [UIColor clearColor].CGColor;
borderLayer.lineWidth = borderWidth;
}
@end

相关讨论

是的！谢谢你。我将为这个答案发布一个 Swift 版本。

de.\\ 的回答对我来说比 CRDave\\ 的回答好得多。

我必须从 Swift 翻译它，所以我想我会继续发布翻译：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37

extension UIView {
func giveBorderWithCornerRadius(cornerRadius r: CGFloat, borderColor c: UIColor, strokeWidth w: CGFloat) {
let rect = self.bounds

let maskPath = UIBezierPath(roundedRect: rect, byRoundingCorners: .allCorners, cornerRadii: CGSize(width: r, height: r))

let maskLayer = CAShapeLayer()

maskLayer.frame = rect
maskLayer.path = maskPath.cgPath

self.layer.mask = maskLayer

let borderPath = UIBezierPath(roundedRect: rect, byRoundingCorners: .allCorners, cornerRadii: CGSize(width: r, height: r))

let layerName =“border_layer”
var borderLayer: CAShapeLayer? = self.layer.sublayers?.filter({ (c) -> Bool in
if c.name == layerName {
return true
} else {
return false
}
}).first as? CAShapeLayer

if borderLayer == nil {
borderLayer = CAShapeLayer()
borderLayer!.name = layerName
self.layer.addSublayer(borderLayer!)
}

borderLayer!.frame = rect
borderLayer!.path = borderPath.cgPath
borderLayer!.strokeColor = c.cgColor
borderLayer!.fillColor = UIColor.clear.cgColor
borderLayer!.lineWidth = w
}
}
